Crash Crusher WHATSAPP30 m³/hour
S30 Mobile Concrete Batching Plants
THE BEST CHOICE FOR PRACTICAL CONCRETE PRODUCTION ON TEMPORARY WORK SITES
ON-SITE TYPE CONCRETE BATCHING PLANT / MB-S30 On-Site Ready-Mix Plants engineered and manufactured by Crash Crusher Global offer a more efficient and economical approach to the production of high quality on small- and medium-sized construction sites and for a range of applications or temporary works. Its clever design and compact structure reduce transport costs and allow production to begin quickly.
PLANT CAPACITY
CONCRETE MIXER
Pan Mixer
0,5 m³/cycle
18,5 kW
STORAGE & FEEDING
4x2,5 m³ Cross Type
From Ground Level
HOPPERS
300 kg
160 kg
15 kg
HIGHLIGHTS / S30
- Easy Transportation
A complete plant, including the concrete transfer conveyor, can be delivered in a single 40‘ Open Top (OT) Container or aboard one standard truck. - Quick Start Up Time
The plant can be started up within just 2–3 hours. - Super Mobility
It can be towed very easily via its integrated hook within the working location, or between different areas on the site. - Zero Foundation
There is no need for a special concrete foundation. A basic flat concrete surface is enough. - Small Installation Area Requirement
The plants require only a small area for installation. There is no need to obtain permission for the installation. - Flexibility in Concrete Production
Four different aggregates can be used in concrete production. - High-Quality Concrete Production
It is very easy to produce high-quality concrete due to the PLC system and the precise weighing system that has been designed for all materials (aggregate, cement, water, additives), allowing weighing in separate weighing batches. - Low Operational and Maintenance Cost
Its simple structure makes it very easy and economical to operate and maintain.
S30 / TECHNICAL SPECIFICATIONS
Metric |
Imperial |
|
| Compacted Concrete Output | 30 m³/h | - |
| Mixer Capacity (Compacted Concrete) | 0,5 m³/cycle | - |
| Mixer Type | Pan Mixer | |
| Mixer Motor Power | 18,5 kW | - |
| Aggregate Bins | 4x25 m³ Cross Type | - |
| Aggregate Feeding | From Ground Level | |
| Aggregate Transfer | Belt | - |
| Air Compressor | Piston Type (4 kW) | - |
| Cement Weighing Hopper | 300 kg | - |
| Water Weighing Hopper | 160 kg | - |
| Additive Weighing Hopper | 15 kg | - |
| Cement Screw Conveyor | Ø 193 x 5.000 mm | - |
Click for the comparison table of technical specifications of Crash Crusher Mobile Concrete Batching Plants.
