APPLICATIONS
The MCSP can be introduced to quarrying, recycling and mining operations where the
following
materials are being processed through a washing
plant:
• Sand & Gravel
• Crushed
Rock
• Crusher dust
• Iron
ore
• Other mineral ores
• Construction
& Demolition Waste Material
WHY Crash Crusher COMPACT SAND PLANT?
• 4th Generation Hydrocylones make better
separation
Facilitates highly accurate separation of silts and clays from
the final washed sand product.
• Replaceable rubber liners for
Hydrocyclone and Pump
Rubber lined pipework ensures maximum wear resistance
to minimise lifetime cost of ownership.
• Efficient
Screening
High frequency vibrating motors ensure a high power to area ratio
ensuring the most efficient dewatering of your sand product.
•
Discharge from top of the unit allows for gravity feed into
thickener
Cyclone overflow containing waste material is discharged at the
highest point of the plant which facilitates easy delivery to water treatment
phase.
HIGHLIGHTS
• Available with Dry-Feed Boxes
• Available in two product output versions
• WS85 Dewatering Panels are widely available trough local
suppliers
• Pump does not require gland water
• Pump & Cyclone has worldwide spare-parts and service
availability through provider
MCSP 90 |
MCSP 150 |
MCSP 210 |
|
Capacity (mtph) | 90 | 150 | 210 |
Maximum Water Requirement (m³/h) | 270 | 450 | 630 |
Cyclone Diameter (mm) | 500 | 660 | 2 x 660 |
Screen Motor Power (kW) | 2 x 2,88 / 1500 rpm | 2 x 7,35 / 1500 rpm | 2 x 6,1 / 1000 rpm |
Dewatering Screen Size (mm) | 1200 x 2400 | 1800 x 2400 | 1800 x 4000 |
Pump Size (inch) | 8"/6" | 10"/8" | 10"/8" |
Pump Power (kW) | 45 | 55 | 75 |
Weight (kg) | 7475 | 10900 | 16750 |
