C30 Compact Concrete Batching Plant
C30 Compact Concrete Batching Plant
ENGINEERED FOR QUICK CONCRETE PRODUCTION ON TIGHT WORK SITES
C30 model is the best choice for low-volume production on small and tight work sites. Combining the advantages of fast installation with a small footprint C 30 is the best choice for construction companies. The installation requires minimum or no foundations, reducing operational costs and bringing mobility to a new level.
PLANT CAPACITY
CONCRETE MIXER
Single Shaft / Planetary Mix
0,5 m³/cycle
18,5 kW
STORAGE & FEEDING
4x7 m³ Cross Type
Ramp or Pre-Feeding System
HOPPERS
300 kg
160 kg
20 kg
HIGHLIGHTS / C30
- Perfect Solution for Tight Site Areas
Due to the ultra-compact design, C 30 Batch plant is the best solution for concrete production in tight sites. - Ultra-Performance and Smart Solution
Crash Crusher C 30 Compact concrete batching plants are flexible, durable, and give class-leading productivity. The plant is preferred by contractors for concrete needs for an efficient, unique, and fast solution. - Suitable for Container Transport
Concerned about Transport costs? Nowhere is too far or too expensive to supply or purchase a proper concrete batching plant, as our C 30 compact model fits in standard 40’ OT containers. - Quick Start Up Time
C 30 compact concrete plants are designed to minimize work on-site during installation and are pre-wired with maximum equipment installed, plumbed, and tested at the manufacturing facilities.
C30 / TECHNICAL SPECIFICATIONS
Metric |
Imperial |
|
| Compacted Concrete Output | 30 m³/h | - |
| Mixer Capacity (Compacted Concrete) | 0,5 m³/cycle | - |
| Mixer Type | Single Shaft / Planetary Mixer | |
| Mixer Motor Power | 18,5 kW | - |
| Aggregate Bins | 4x7 m³ Cross Type | - |
| Aggregate Feeding | Ramp or Pre-Feeding System | |
| Aggregate Transfer | Skip | - |
| Air Compressor | Piston Type (5,5 kW) | - |
| Cement Weighing Hopper | 300 kg | - |
| Water Weighing Hopper | 160 kg | - |
| Additive Weighing Hopper | 20 kg | - |
| Cement Screw Conveyor | Ø 193 x 11.500 mm | - |
Click for the comparison table of technical specifications of Crash Crusher Mobile Concrete Batching Plants.
